Premium laptops
Product image
Operating system
|
Feature
|
Description
|
|
Preinstalled
|
Windows 11 Pro for Workstations 64
|
Processors
|
Specification
|
Description
|
|
ntel Core i5-8400 processor
|
Up to 4.0 GHz with Intel Turbo Boost Technology (3.0 GHz base frequency)
9 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
65 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Graphics
|
Feature
|
Description
|
|
Graphics cable adapters
|
Nvidia GT 730 4GB
|
Memory
|
Specification
|
Description
|
|
Standard
|
(4) UDIMM slots supporting dual-channel memory
4 GB, 8 GB, 16, and 32 GB UDIMMs
|
|
Supported configurations
|
8 GB (1 x 8 GB) DDR4-2666 ECC
16 GB (2 x 8 GB) DDR4-2666 ECC
32 GB (4 x 8 GB) DDR4-2666 ECC
32 GB (2 x 16 GB) DDR4-2666 ECC
64 GB (4 x 16 GB) DDR4-2666 ECC
64 GB (2 x 32 GB) DDR4-2666 ECC
128 GB (4 x 32 GB) DDR4-2666 ECC
4 GB (1 x 4 GB) DDR4-2666 non-ECC
8 GB (2 x 4 GB) DDR4-2666 non-ECC
8 GB (1 x 8 GB) DDR4-2666 non-ECC
16 GB (2 x 8 GB) DDR4-2666 non-ECC
32 GB (4 x 8 GB) DDR4-2666 non-ECC
32 GB (2 x 16 GB) DDR4-2666 non-ECC
64 GB (4 x 16 GB) DDR4-2666 non-ECC
64 GB (2 x 32 GB) DDR4-2666 non-ECC
128 GB (4 x 32 GB) DDR4-2666 non-ECC
|
|
Maximum
|
Up to 128 GB
|
Monitors/displays
|
Feature
|
Description
|
|
Supported
|
HP Z Display Z27n G2 27-inch IPS LED Backlit Monitor
HP Z Display Z24n G2 24-inch IPS LED Backlit Monitor
HP Z Display Z24nf G2 23.8-inch IPS Backlit Monitor
HP Z Display Z23n G2 23-inch IPS LED Backlit Monitor
HP Z Display Z22n G2 21.5-inch IPS LED Backlit Monitor
|
Storage and drives
|
Feature
|
Description
|
|
SATA 8.89 cm (3.5 in) Hard Drives
|
500 GB SATA 6 Gb/s 7200 HDD
1 TB SATA 6 Gb/s 7200 HDD
2 TB SATA 6 Gb/s 7200 HDD
4 TB SATA 6 Gb/s 7200 HDD
6 TB SATA 6 Gb/s 7200 HDD
500 GB SATA 7200 rpm SED SFF HDD
1 TB 7200 RPM SATA 8 GB SSHD Drive
1 TB Enterprise SATA 7200 HDD
|
|
SATA SSD
|
HP 256 GB SATA SSD
HP 512 GB SATA SSD
HP 1 TB SSD
HP 2 TB SATA SSD
HP 256 GB SATA SED Opal2 SSD
HP 240 GB Enterprise SATA SSD
HP 480 GB Enterprise SATA SSD
Storage Acceleration
16 GB Intel Optane memory (sold separately)
|
|
PCIe Solid State Drives
|
PCIe SSDs for HP Workstations
HP Z Turbo Drive G2 256 GB TLC PCIe SSD
HP Z Turbo Drive G2 512 GB TLC PCIe SSD
HP Z Turbo Drive G2 1 TB TLC PCIe SSD
HP Z Turbo Drive G2 2 TB TLC PCIe SSD
Intel 905p Series SSD (Optane SSD)
Intel Optane SSD 905p 280 GB AiC
Intel Optane SSD 905p 480 GB AiC
|
|
Removable storage
|
HP 9.5 mm Slim DVD Writer
HP 9.5 mm Slim DVD-ROM Drive
HP 9.5 mm Slim BDXL Blu-ray Writer
|
|
HDD Frame/carriers
|
HP DX175 Removable HDD Carrier
HP DX175 Removable HDD Frame/Carrier
|
|
Media card reader
|
HP SD Media Card Reader
|
Ports/slots
|
Specifications
|
Description
|
|
Ports
|
Front side
(1) Power button
(1) Headphone/microphone combo jack
(1) USB 3.0 Type-A charging data port
(1) USB 3.0 Type-A data port
(1) USB 3.1 Gen 2 Type-C charging data port (optional)
Back I/O ports
(1) Audio Line-In
(1) Audio Line-Out
(2) DisplayPort (DP) 1.2 outputs (from Intel UHD graphics; select models)
(1) Flexible module port output (optional flexible module required)
(2) USB 2.0 ports
(4) USB 3.0 ports
(1) Serial port (optional)
(2) PS/2 (optional)
(1) Parallel port (optional)
(1) RJ-45
(1) DC Input
Internal I/O ports
(1) USB 3.0 port
(2) USB 2.0 ports
|
|
Controller card
|
HP Thunderbolt 3 PCIe 3-port I/O Card
|
|
Rear module options
|
HP Flex IO module (VGA)
HP Flex IO module (HDMI)
HP Flex IO module (DP)
HP Flex IO module (USB-C)
HP Flex IO module (1 GbE LAN)
|
|
Expansion slots
|
(1) PCIe Gen3 x16 slot
(1) PCIe Gen3 x4 slot/x16 connector
(1) PCIe Gen3 x1 slot/x4 connector
(1) PCIe Gen3 x1 slot/x4 connector
(2) M.2 storage (PCIe Gen3 x4)
(1) SD Card Reader (optional)
(1) M.2 WLAN (PCIe Gen3 x1 and Intel CNVi)
|
Audio/multimedia
|
Feature
|
Description
|
|
Integrated audio
|
Conexant CX20632 5.1 HDA codec
|
Networking/communication
|
Feature
|
Description
|
|
Integrated
|
Intel I219LM PCIe GbE Controller (Intel vPro with Intel AMT 12.0)
Intel X710-DA2 2-Port 10GbE SFP and NIC
HP 10GbE SFP and SR Transceiver
Intel X550-T2 2-Port 10GbE NIC
Intel 9560 802.11a/b/g/n/ac with Bluetooth 5 M.2
Intel I350-T2 2-Port 1GbE NIC
Aquantia AQN-108 1-Port 5GbE NIC
|
Power
|
Specifications
|
Description
|
|
Power supply
|
650 W Power supply
90% efficiency
Wide-ranging
Active PFC
500 W Power supply
90% efficiency
Wide-ranging
Active PFC
250 W Power supply
85% efficiency
Wide-ranging
Active PFC
|
|
Rated input current
|
6 A at 100 to 240 V
|
|
Operating voltage range
|
90 to 269 VAC
|
|
Operating line frequency range
|
47 to 66 Hz
|
Take processing to record speeds
Crush demanding single and multi-threaded workflows and take on aggressive multi-tasking without throttling. We redesigned our proprietary motherboard to give you full performance, while keeping components running cool and quiet.
Built to expand
Need to swap graphics cards? Increase CPU power? Add specialized PCIe cards? Go for it. Our most expandable entry workstation is an investment that will last for years.
Safeguard your data. Protect your privacy.
Advanced security features come standard on every Z2 Tower. System safeguards like HP Client Security Suite Gen31 and HP Sure Start Gen42 – the industry’s first self-healing BIOS – mean your device is locked down tight, so your data and identity are too.
Windows 11 Pro 64
Work without compromising on performance or security with Windows 10 Pro, powered by HP’s collaboration and connectivity technology.
Intel® Core™ i7 processor
Get high-end performance for intensive tasks like rendering and video editing with the Intel® Core™ i7 processor.3
Self-encrypting drives
With optional self-encryption drives, you have confidence knowing that if your storage device falls into the wrong hands, your valuable IP cannot be accessed.4
