Cause
1. Front View
1 | Left Microphone | 2 | Camera |
3 | Camera Status light | 4 | Right Microphone |
5 | Display | 6 | Battery Status LED |
2. Top View
1 | Power Button | 2 | Keyboard |
3 | Palm Rest | 4 | Fingerprint reader |
5 | NFC Sensor | 6 | Touch Pad |
7 | Pointing Stick |
3. Left View
1 | Power Connector Port | 2 | DisplayPort over USB Type-C (optional Thunderbolt 3) |
3 | HDMI Port | 4 | USB 3.0 Port |
5 | USB 3.0 Port with PowerShare | 6 | Smart Card Reader |
4. Right View
1 | Universal audio jack | 2 | Micro SD port |
3 | SIM card tray (optional) | 4 | USB 3.0 Port |
5 | Network (RJ45) Port | 6 | Security Lock Slot |
Resolution
5. Chassis LED’s
Power LED
The power button LED indicator light is located near the upper right side of the system, as shown below.
Power State
|
LED Behavior
|
On (S0)
|
Solid White
|
Hibernate (S4)
|
Off
|
System off (S5)
|
Off
|
Battery Charge LED
The battery charge LED indicator is located at the front of the system, as shown below.
Power Source
|
Battery Charge Level
|
LED Behavior
|
AC adapter
|
Fully charged
|
Off
|
AC adapter
|
Charging
|
White
|
Battery
|
> Low to fully charged
|
Off
|
Battery
|
Low to critically low
|
Solid Amber
|
